T3 Series Bacnet Programmable controller

Name: T3 Series Bacnet Programmable controller
SKU: 4404
Availability: InStock

$125.00 – $266.00

The T3 series Bacnet programmable controller is a low cost performer with big system features. There are three versions with various I/O configurations and can be expanded with external i/o modules to form a complete building automation solution.

Product Highlights:

Sturdy construction, consistently gets good comments from our clients.
UL listed ABS enclosure with rubberized texture creates a high end feel
Software configure the I/O ranges with the free T3000 software or by writing to the registers with your own software
Each output has a hand-off-auto switch for easy troubleshooting and overrides
Universal I/O can be configured for nearly any sensor, no jumper settings required.
Each I/O as well as the RS485 connections have a separate screw terminal
Connect over Ethernet,RS485, Zigbee and USB.
Supports Modbus RTU and Bacnet protocols simultaneously.
Starter space source code is avaliable
T3000 front end is free and open source: http://tinyurl.com/n7kkqp6
Compiled version of the front end is here: https://tinyurl.com/y7uyu9n3

Brochure PDF T3000 Software Source Code UL and CE T3 Controller Wiring Diagram CAD

Online Help

3 Series Bacnet Programmable controller

Using these controllers, the building operator can manage typical HVAC systems including chillers, boilers, VAVs, air handlers from an intuitive graphical front. All systems are shown on screen with graphical floorplans and system diagrams. The software is free so there are no licences or monthly cloud service fees. Systems can be built up from a single controller all the way up to campus type environments with multiple buildings and thousands of devices. All communications takes place using industry standard bacnet and modbus protocols, together with an open source front end this system can be considered the most open system of its kind.Each controller has Ethernet and RS485 ports and supports both modbus and bacnet protocols on any of these ports. Besides,the data can be routed from one protocol to another over any port.

*The 2 universal outputs can be selected by jump as either 1-10V analog or relay outputs.

**Zigbee module.

Setup and programming are done on a PC, all settings, i/o configuration, programming, floorplans and alarms are set up in the T3000 front-end software. Once the programming is done,you can save the program for backup or load it into another controller. It’s very easy to edit the logic since the T3000 software serves not only as the front-end for the building operator but also as the back-end for the controls technicians.

Dimensions:

Part Number Scheme:

Works with: https://bravocontrols.com/product/bacnet-room-setpoint-temp-display/
