The sensor is housed in a copper tube with a slightly curved surface to make intimate thermal contact with the pipe. Temperature changes in the pipe fluid are conducted very quickly through the sensor housing to the element inside. The copper pipe strap fits makes for quick installation on either 1/2 inch or 3/4 inch pipes.
The 3 meter long cable is 24 AWG stranded copper wire with a UL2651 rating and is registered under UL file number UL42323. The thermistor is a 10K type 2 temperature curve compatible with most DDC systems on the market
Product Highlights:
• 10k thermistor with type 2 temperature curve, compatible with major control systems.
• Fast thermal response design, 90% response of step change in under 5 seconds
• Accurancy of ±0.2C over the range of 0-70℃
• Interchangeable, calibration not required for most applications
• Excellent long-term stability
• Operating range up to +150℃
• UL2651 cable with UL file number UL42323
This sensor is used to measure the outside air temperature to allow the DDC system to coordinate the mechanical systems with actual building load conditions, enabling such strategies as free cooling, optimum start/stop, and supply temperature reset. The housing is made from PVC and stainless steel fittings which shield the probe from direct sunlight. There are three thermistor based models, and one RTD version to provide compatibility with the majority of DDC systems.
The strap-on Insert sensor consists of a stainless steel sheath temperature sensor, thermal conducting compound, and an adjustable pipe bracket accessory. The stainless steel sheath temperature sensor is suitable for direct application to pipe surfaces for chilled or hot water measurement.
This sensor is used to measure the supply and return temperature in HVAC system. The flange mount design makes it easy to install the sensor in tight quarters. There are several sensor elements to choose from which guarantee compatibility with all popular DDC systems. The probe in the photo is our standard model which is always in stock, it has a 8″ probe and a 120″ cable, and employs either a precision thermistor or platinum film sensor, so field calibration is not required. The 10ft(3m) cable is “Plenum Rated”.
The duct sensor is used to measure the supply and return air temperature in HVAC system. There are several sensor elements to choose from which guarantee compatibility with all popular DDC systems. There is a precision thermistor. The probes are epoxy sealed to prevent moisture from migrating into the probe. Field calibration is not generally required. The standard probe length is 12 inch. Custom probe lengths, wire types and sensor elements are available for large OEM projects. Ask about our plastics & metal manufacturing capabilities for custom housings as well.
The room sensors are used to provide reliable, accurate temperature readings in surface-mount room environments, Energy Management Control Systems, compatible with all the leading control systems.They feature a standard plastic ventilated enclosure.
